On November 24, 2022, CIQTEK successfully held the new electron microscope launch event "Make the Invisible, Visible". Based on the diversified needs of users, CIQTEK launched SEM3300, which "Redefines Tungsten Filament SEM"; SEM2000, which is "Easy But Not Simple"; SEM4000, which is "Super High Beam Current, Super Fast Analysis".     >> SEM3300 In the new product launch session, CIQTEK Vice President Feng Cao introduced three new electron microscopes in detail. The first to be unveiled was the SEM3300, a tungsten filament scanning electron microscope, which is a perfect blend of technology and industrial design. With a resolution of 2.5 nm at 20 kV, a 16% improvement over ordinary tungsten filament electron microscopy, a resolution of 4 nm at 3 kV, a 2-fold improvement, and a resolution of 5 nm at 1 kV, a 3-fold improvement, the SEM3300 has significantly surpassed ordinary tungsten filament electron microscopy in all voltage bands, redefining the industry standard for tungsten filament scanning electron microscopy.Take the diaphragm material in lithium batteries as an example, the details of the conventional tungsten filament electron microscopy are blurred and unclear (Figure a below), while the diaphragm pictures taken by SEM3300, the diaphragm pores are clearly visible and the edges of the pores are sharp (Figure b below).   Figure a: Li-ion battery septum photographed by conventional tungsten filament electron microscopy, with blurred details.   Figure b: SEM3300 photographed lithium battery diaphragm, diaphragm pores clearly visible, sharp edge of the hole.     >> SEM2000 Tungsten filament SEM2000 is a product that is not fussy in its operation. It is built with the goal that everyone is able to use it, with a simple interface and rich expandability. If you want a simpler tool, SEM2000 will be your best choice.   >> SEM4000 The Field Emission Scanning Electron Microscope SEM4000 is a new product for analytical users' needs. It features a high electron beam current and fast analysis speed, with a maximum electron beam current of over 200 nA and continuously adjustable beam size, which facilitates the selection of the most suitable imaging and energy spectrum conditions.   Make achievements for customers, make achievements for peers Dr. Yu He, CEO of CIQTEK, expressed his gratitude to all the guests for their care and support of CIQTEK in his speech. Dr. Yu He said, CIQTEK engraved innovation in its genes, put customers in its heart, insisted on pragmatic innovation with "no compromise", and developed the new product SEM3300 which redefines the industry standard of tungsten filament electron microscope, allowing the tool to return to the tool itself so that users can better rest assured in scientific research. At the end of the conference, CIQTEK Vice President Wan Legend announced the winners of the "Watch Live, Get a Free Electron Microscope (One Year Access)" event. Mr. Zh...

The Excellent Oral Presentation Awards are presented during the closing ceremony of the 12th Asia-Pacific EPR Symposium (APES2022) on November 7th, 2022. CIQTEK is pleased to sponsor this award to scientists who have contributed significantly to electron paramagnetic resonance (EPR or ESR) research. This time, congratulations to Dr. Shen Zhou from the National University of Defense Technology, Dr. Sergey Veber from the International Tomography Center of SB RAS, and Dr. Zhiyuan Zhao from the University of Science and Technology of China for winning the awards.APES 2022, Webinar, November 4-7, 2022CIQTEK is happy to sponsor the APES 2022 during November 4-7, 2022. The symposium this year is an online event for international speakers and participants, a new start for Asia-Pacific EPR/ESR Society in the post-epidemic era. The main aims of APES 2022 are to bring together EPR/ESR spectroscopists and to promote and facilitate collaboration among the EPR/ESR community. APES 2022 is intended to stimulate discussions on the forefront of research in all aspects of EPR/ESR ranging from theoretical and experimental advances in CW/Pulsed EPR, high frequency, and high field EPR, ENDOR, PEDLOR/DEER, time-resolved EPR, FMR, MRI, ODMR to applications in medicine, biology, chemistry, materials science and nanotechnology. On November 6, Dr. Sergey Veber gave a presentation entitled "X-band EPR spectrometer based on MW bridge with 300 W solid-state amplifier and AWG unit". Abstract of the PresentationTechnical advances in modern EPR spectrometers set up the frontiers of EPR-related methodologies and approaches. Considering EPR spectrometers of conventional microwave bands, such as X- and Q-, high-power amplifiers, arbitrary wave generators, and fast digitizers are the essential units required for up-to-date pulse EPR techniques.Herein we describe an X-band EPR spectrometer constructed in the Magnetic Resonance Laboratory of Biomolecular Systems (NIOCH SB RAS) and featuring all the required equipment to perform state-of-art pulse EPR experiments. Among the general construction of the spectrometer, the scheme of the microwave bridge is considered in detail including a pulse-forming and pulse-monitoring unit, and a low-noise amplifier with a pulse protection circuit. A modular open-source software "Atomize" (https://github.com/Anatoly1010/Atomize) is used to control the spectrometer including AWG and fast digitizer cards featuring high-speed data streaming. A wideband dielectric EPR resonator was developed to fit the requirements for AWG experiments with chirp pulses. The spectrometer is designed to have a high dynamic range, low coherent noise and to capture the direct dimension efficiently. These capabilities were demonstrated with both rectangular and AWG pulse experiments. This work was supported by the Ministry of Science and Higher Education of the Russian Federation (grant 14.W03.31.0034)Biography of Dr. Sergey VeberDr. Sergey Veber received his Ph.D. in 200...

CIQTEK generously sponsored an annual lectureship and award, given to a young scientist who has made a great contribution to electron paramagnetic resonance (EPR or ESR) research. At the 12th Asia-Pacific EPR/ESR Symposium (APES 2022), the CIQTEK Sponsored Young Scientist Award was awarded to Dr. Fei Kong, CAS Key Laboratory of Microscale Magnetic Resonance and School of Physical Sciences, University of Science and Technology of China.As winner of the 2022 competition, Dr. Fei Kong was invited to gave a prize lecture at the conference, on November 6th.APES 2022, Webinar, November 4-7, 2022CIQTEK is happy to sponsor the APES 2022 during November 4-7, 2022. The symposium this year is an online event for international speakers and participants, a new start for Asia-Pacific EPR/ESR Society in the post-epidemic era. The main aims of APES 2022 are to bring together EPR/ESR spectroscopists and to promote and facilitate collaboration among the EPR/ESR community. APES 2022 is intended to stimulate discussions on the forefront of research in all aspects of EPR/ESR ranging from theoretical and experimental advances in CW/Pulsed EPR, high frequency, and high field EPR, ENDOR, PEDLOR/DEER, time-resolved EPR, FMR, MRI, ODMR to applications in medicine, biology, chemistry, materials science and nanotechnology.Abstract of the Lecture: Zero-field EPR spectroscopyThe nitrogen-vacancy (NV) centers in diamond can promote the sensitivity of EPR detection to a single-spin level even under ambient conditions, and thus enable single-molecule EPR spectroscopy [Science. 347, 1135–1138 (2015); Nat. Methods 15, 697–699 (2018)]. A key figure of single-molecule EPR is that it can resolve heterogeneous molecular information, which is averaged in conventional EPR measurement. However, the current single-molecule measurements are insufficient to do so, due to the poor spectral resolution. Here, I will introduce an easy way to substantially improve the spectral resolution, i.e., removing the magnetic field. The zero-field EPR has been well-studied for decades [Chem. Rev. 83, 49–82 (1983)]. It has narrower spectra with the tradeoff of much poorer sensitivity. Difference from conventional inductive detection, the signal of NV-EPR comes from the statistical fluctuation rather than the thermal polarization of spins, which does not depend on the magnetic field. Therefore, the NV center is an ideal sensor for zero-field EPR detection. I will show that the NV-EPR has the advantage in not only spatial resolution but also spectral resolution.Biography of Dr. Fei KongDr. Fei Kong was born in Hefei, China. In 2012 he obtained a B.Sc. degree at the University of Science and Technology of China (USTC) and later undertook experimental research there on control and simulation using nitrogen-vacancy centers in diamond with Prof. Dr. Jiangfeng Du and Prof. Dr. Fazhan Shi. He received a Ph.D. degree based on this work in 2018. After 3 years of postdoctoral research on t...

CIQTEK Appoints L.A.Systems Incorporated (LAS) as the Japan distributor for the range of EPR (ESR) Spectrometers and Scanning NV Microscope (SNVM). CIQTEK is pleased to announce LAS as our sales representative for the range of Electron Paramagnetic Resonance (EPR or ESR) equipment and Scanning NV Microscope in Japan. LAS will work closely with the CIQTEK team to provide complete service to Japanese-speaking customers. Check the CIQTEK products on the LAS website: https://www.las.jp/products/hardware_CIQTEK.htmlSince its establishment in 1993, LAS has successfully become a major distributor of foreign-produced software and hardware in Japan. The team always strives to improve the R&D environment for customers. Click on the logo image below for more information about LAS.

CIQTEK Appoints SciMed as the UK and Ireland distributor for the range of EPR (ESR) Spectrometers. CIQTEK is pleased to announce that we have entered into a partnership with SciMed to appoint them as the new UK distributor for the range of Electron Paramagnetic Resonance (EPR or ESR) Spectrometers. Since its founding in 1979, Scientific & Medical Products (SciMed) has been a highly successful distributor of laboratory and process equipment. SciMed exclusively represents a number of leading manufacturers in the UK and Ireland and has recently been appointed the distributor for several companies in France and other selected regions around Europe.The focus of SciMed is on the promotion, sales, service and support of innovative and world-class products to customers in industry and academia.SciMed will offer UK based sales and service support for this range of products and work closely with the CIQTEK team to offer the usual outstanding support to UK users.Check the CIQTEK EPR (ESR) Spectrometers on SciMed website: https://www.scimed.co.uk/product-category/electron-paramagnetic-resonance/

Images are ubiquitous in our lives and are a fundamental and indispensable medium for the dissemination of information. Imaging is a direct means of acquiring images and can be classified according to the different imaging wavelengths as visible, radar, infrared, and terahertz imaging. With the further development of information technology, new demands are being placed on spatial resolution, signal-to-noise ratio, multispectral imaging performance, and the imaging environment.  Single-pixel Imaging Technology   With the increase in computer arithmetic power and the development of compressed perception theory, scientists have proposed a single-pixel imaging technique based on a computational imaging approach. This is a new imaging method that uses a single-pixel detector without spatial resolution and a spatial light modulator to obtain images by reconstruction. Compared with the traditional array detector imaging method, single-pixel imaging has the advantages of high sensitivity and interference resistance and has obvious advantages in the fields of very weak light imaging, non-local imaging, special band detection without large surface array detectors, etc. It has very broad application prospects in many fields such as nuclear magnetic resonance, aerospace remote sensing, and terahertz imaging.   Advantages of Single-pixel Imaging  Image Credits: High throughput dual-wavelength temperature distribution imaging via compressive imaging.Opt. Comm. 410, 287-291 (2018)   Single Pixel Photon Imaging Teaching Instrument   Although computational imaging, represented by single-pixel photon imaging, is promising, there is still a lack of experimental teaching content at the undergraduate level. In order to improve the relevant curriculum and help students develop their scientific research skills, CIQTEK, in collaboration with Professor Qing Zhao's team from the Technology Research Centre of Beijing University of Technology, has created a single-pixel photon imaging teaching instrument.   The product is a teaching instrument based on the theory of compressed perception and photon counting imaging technology, using digital micromirror devices to accomplish rapid imaging of random spatial light-modulated target objects. The product takes advantage of the sparse signal characteristics of the compressed sensing technique to go beyond the traditional Shannon sampling theorem and can restore images with high spatial resolution and high signal-to-noise ratio in very low light conditions with fewer measurements.   CIQTEK Launched Single Pixel Photon Imaging Teaching Instrument   The single-pixel photon imaging teaching instrument has a wealth of hardware modules to support students' hands-on adjustment and construction, facilitating students' understanding of spatial light modulation techniques and equipment usage, understanding the principle of compressed perception and imaging methods, and knowing the characteri...

Recently, the General Office of the General Administration of Market Supervision and Administration of China issued the "Notice of the First Batch of National Innovation Bases of Metrology and Science Popularization Resources", officially granting CIQTEK the national qualification of Science Education Innovation Base.      CIQTEK New Metrology Science Museum (Rendering)   In the past six years since its establishment, CIQTEK has not only achieved a series of internationally influential scientific research results in the fields of precision measurement and computing but also set up a science division specializing in measurement and science education.   The CIQTEK Science Education Base covers an area of over 1,500 square meters, with the measurement and science laboratory, an exhibition hall, and a lecture hall, with more than a thousand exhibits, teaching aids, audio and video, animations, and other forms of atomic force microscopes, laser distance measuring instruments, etc.   Up to now, CIQTEK Science Education Base has held a series of colorful science activities such as the "Precision Measurement Instruments Exhibition", "Infinite Possibilities Technology Science" and "Science Seminar for Primary School Students", and the total number of visitors has reached 15,000.     Science education activities organized by CIQTEK In order to better promote metrology culture and science education activities, CIQTEK is preparing to build a new 3,000-square-metre science base featuring metrology, which is expected to be put into operation in September 2023. The new base integrates metrology, science education, science, and technology experience, science and innovation education, scientific investigation, scientific experiments, and online-offline linkage, and is an important place for young people and the public to receive metrology culture, metrology science popularization and science and innovation education practice.   CIQTEK New Metrology Science Museum (Rendering)   With the design concept and the innovative form of science popularisation combining experience and immersion as the distinctive features, the base will strive to become a first-class and distinctive modern metrology science museum in the future.

In September 2022, CIQTEK Scanning Electron Microscope (SEM) was delivered to Prof. Xiaochun Liu's team, which has been commissioned and officially put into operation. Through a short interview, Prof. Liu shared his experience of using CIQTEK SEM. In the video, Prof. Liu said that thanks to the excellent functions and superb value of CIQTEK SEM, the future working time will be very happy.    Check the video on YouTube: https://youtu.be/nE-uYr1uFCc     At present, CIQTEK has launched field emission scanning electron microscope and tungsten filament scanning electron microscope.   CIQTEK Field Emission Scanning Electron Microscope SEM5000 CIQTEK Field Emission Scanning Electron Microscope SEM5000 The SEM5000 is a high-resolution, feature-rich field emission scanning electron microscope. With an advanced lens barrel design, the lens barrel has a deceleration, low aberration, and no magnetic leakage objective lens design, which realizes low-voltage high-resolution imaging, and can be applied to magnetic samples at the same time. SEM5000 has optical navigation, complete automatic functions, well-designed human-computer interaction, and optimized operation and use procedures. Regardless of whether the operator has extensive experience, they can quickly get started and complete high-resolution shooting tasks.     CIQTEK Tungsten Filament Scanning Electron Microscope SEM3200 CIQTEK Tungsten Filament Scanning Electron Microscope SEM3200 The SEM3200 is a high-performance, versatile general-purpose tungsten filament scanning electron microscope. It has excellent image quality, is compatible with low vacuum mode, and can obtain high-resolution images in different fields of view. Large depth of field, the imaging is full of three-dimensional effects.
